10cbm Capacity Volume Concrete Mixer Truck HOWO 6x4 Sinotruk Cement
Mixer Truck
Description:
• Key Application
1. Small mixer truck, light duty mixer truck, suitable for the
tunnel and other special narrow area.
2. Professional mixer truck manufacturing, we accept the special
design and nominated brands of mixer parts.
3. We adopt the SINOTRUK HOWO heavy duty chassis and light duty
chassis to suit for different size of mixer body.
4. The SINOTRUK HOWO heavy duty chassis suitable for 6cbm~12cbm
mixer body.
5. There are geometric volume and effective volume for the mixer
body. The geometric volume is 9.2cbm and the effective volume is
6cbm.
The geometric volume 12.5cbm and the effective volume is 8cbm; the
geometric volume 15cbm, the effective volume 10cbm.
The geometric volume 18.5cbm, the effective volume 12cbm.
Advantages
1. Centralized Lubricating System for Easy Maintenance
2. Closed Circuit Hydraulic Rotation System
3. Spacious Driver's Cab with Shovel Loader Weigher, A/C and Fire
Extinguisher inside.
4. The product parameters are just a reference, not absolute.If you
think the configuration is reasonable, you can order directly.If
you have your own list of parameters, we can tailor it to your
needs.
5. The price shown in the product introduction is a range price,
and the final price is determined according to the configuration of
the product and the quantity ordered.
Specifications:
SINOTRUK HOWO 6X4 Mixer Truck (LHD)
| Cabin | HOWO 76 Standard Cab With two bunks, 70° hydraulically tillable to the front as attached
photo for ref. | |
| Vehicle Main Dimensions | (L x W x H)mm | 8825x2500x3850 |
| Wheel base (mm) | 3825+1350 |
| Wheel track (front/rear) (mm) | 2022/1830 |
| Approach/Departure angle(°) | 16/20 |
| Weight in KGS | Tare Weight | 14410 |
| Loading Capacity | 10500 |
| Front axles loading capacity | 1x8000 |
| Rear axles loading capacity | 2x16000 |
| Max. driving speed(km/h) | 90 |
| Engine | Brand | Sinotruk |
| Model | WD615.47 |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling,
turbo-charging and inter-cooling |
| Horse Power(HP) | 371HP |
| Emission standard | Euro Ⅱ |
| Gearbox | HW19710 , 10 forwards & 2 reverse |
| Clutch | Reinforced diaphragm clutch, diameter 430mm |
| Steering Gear | ZF 8098,power steering, hydraulic steering with power assistance |
| Fuel tank (L) | 300 |
| Tire | 12R22.5 tire , 11 pieces |
| Brakes | Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air
operating on rear wheels Auxiliary brake: engine exhaust valve brake |
Mixer Body
Thickness | End plate | 6mm in high tensile strength steel |
| Mixer body | 5mm in high tensile strength steel |
| Mixer body Volume | M3 | 6 M3 |
Hydraulics | Motor | Eaton brand |
| Pump | Eaton |
Details:
Shipping:
Complete Chassis sand blasting to clean rust, 1 coat of anti-rust
prime,2 coats of final pain
Roll on roll off (RORO) ship
It's the specialized ship to transport cars and trucks, which has
power wheel, it's the best way of truck transportation.
Bulk carrier ship
It's the specialized ship to transport grain, coal, ore, salt,
cement ,etc, dry and bulk goods, can also used to transport
trucks,price is cheap, but the truck always be put on the deck, sea
water will damage the truck painting.
Container ship
It's well-known shipping way, and also the highest cost among these
three ways. Few sea port only container ship can arrive, so
sometimes, we have to use container ship.
