5 Compartments Aluminum Fuel Tank Trailer

Description:

The tank body of the aluminium tank truck is made of 5083 aluminium alloy with light weight and large volume. The vehicle is also equipped with an vapor recovery system to reduce the waste of oil and gas. Brake interlocking system ensures vehicle safety. The main beam is made of aluminium alloy 6061. It has high strength, good quality and light weight. It reduces the weight of vehicles and can bear more weight.

Advantages:

• Large volume

The aluminium alloy tank truck has a large volume of 50000L, which can carry more oil and save transportation cost.

• Beautiful appearance

The tank body is made of aluminium alloy 5083. After forming, it will be polished. The outside surface of the tank is like a mirror. It is very beautiful and does not need any paint.

Specifications:

Dimension
Tare Weight	7600KGS
Overall Length	13000mm
Total Height	3800mm
Overall Width	2500mm
Tank Body
Shape	Elliptical or round or square round
Total Volume(m3)	50000L
Tanker Body Material	6mm aluminium alloy
End Plate	7mm aluminium alloy
Manhole Cover	Jialong manhole cover with PV vent, overfill holes and vapour transfer vent hole, lockable
Vapor Valve	Jialong vapor valve mounted in each compartment
Compartment	5
Discharging Valve	API adaptors with dust cap
Piping	4”alu discharge pipes with minimum number of bends
Vapor recovery system	With Vapor recovery system
Overfill system	overfill optic sensor with 5 wires optic socket
Chassis
Main Beams material	Aluminum 6061 chassis I beam
Axle	3 axles, “FUWA” 13 Tons 1820mm/ABS;drum brake
Landing Gear	JOST brand E200 Two-speed, manual operating, heavy duty landing
King Pin	JOST brand 50# 2” bolt-in king pin
Suspension	FUWA Air Suspension system and air bag
Braking System	“WABCO”ABS 4S/2M ;T30/30+T30 Spring brake chamber
Wheel Rim	9.0-22.5 steel wheel rim
Tire	China Brand Triangle 12R22.5 tubeless tire with one spare tire
Painting	No painting
Accessories	Tool box
Gallery
