V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss

Description:

• Core Application

V shape dry bulk tank trailer fits for bulk transportation of building materials, metal powder, coal combustion products etc. Usually, it finishes transportation tasks assigned by building enterprises.

• V Shape

This product is configured with three axes. The V shape of the tank structure has a lot of notable characteristics: low gravity center, superior balance, fast loading and unloading etc.

• Long Life Cycle

The anti-corrosion coating on the inner wall and anti-rust paint on the outer wall perfectly protects the tank. Thus, the life cycle of the tank is prolonged.

Advantages:

• Quality Assurance

The quality of the trailer is on the basis of the durable steel plate, firm welding technology, and strict quality evaluation.

• Small Discharge Loss

Our trailer is equipped with a fluidized belt inside that can be used with an air compressor to efficiently unload powder with a small amount of residue. Accordingly, cement loss can be diminished.

• Protect the Quality of Cement

Special containers are adopted during transportation and storage. It is not easy to get wet and cement can be stored for a long time without deterioration.

Specifications:

Overall Size	12500mm x 2500mm x 3800mm
Capacity	60 tons
Tank Body	Q235A/6mm steel sheet
End Plate	Q235A/6mm ball shape
Axle	13T/16T capacity, FUWA / BPW Brand
Suspension	Mechanical suspension or air suspension
Leaf Spring	Leaf spring or air bag
Floor	Checkered plate
Tire	11.00R20, 12.00R20, 11R22.5, 12R22.5, 315/80R22.5 for option
Wheel Rim	Optional range: 8.5-20, 9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Discharge Pipe	4" seamless steel tube
Engine	Diesel engine or electrical motor
Air Compressor	37Kw, 0.2Mpa.1000r/min
Kingpin	2’’/3.5’’ bolt-in king pin
Landing Gear	JOST brand two-speed, manual operating, heavy duty landing gear
Air-charging System	2 main hole, 2check valve, 1.5" safe valve, 0.4Mpa guage
Outlet Discharge Pipe	4" rubber hose 6m
Braking System	WABCO RE6 relay valve; T30/30 spring brake chamber; 40L air tanks
Painting	Complete chassis sand blasting to clean rust; 1 coat of anti-corrosive prime; 2 coat of final paint
Accessories	One standard tool box
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
