100CBM LPG Storage Tank

Description:

• Key Application
LPG storage tank is usually applied in the cryogenic liquid storage of various gas fuels. Other oil and chemical raw materials can be stored as well. The LPG vessel is diffusely used in many areas like: gas industry, hospital, smelting and cutting of metal. The 100CBM tank can satisfy the large gas consumption.

Advantages:

• Rotproof Tank
The surface of the tank is dealt with advanced technologies e.g.: sandblasting, spraying coat, sweeping etc.

• Light Running Gear
The light running gear maximizes the valid capacity and reduces operating costs.

• Stable Performance
The rigorous and scientific production technology ensures the minimum shrinkage ratio and the maximum stability in the low temperature.

• Customized Configuration
Depending on different mediums, the following tank material can be offered: carbon steel, stainless steel, manganese steel etc. The tank shape varies with transport requirements, including ellipse, monoblock, and round. Insulation devices can be optionally installed, like heating tube, thermal barrier etc. Air or mechanical suspension is equipped for customers' requirement.

Specifications:

Tank	Tank Volume	100CBM
	Model	Horizontal
	Type	Chemical Tank
	Applicable Material	LPG
	Design Pressure(MPa)	1.77
	Max. Operating Pressure(MPa)	1.61
	Hydrostatic Pressure(MPa)	2.22
	Air Tight Pressure(MPa)	1.77
	Corrosion Allowance	1.0mm
	Design Temperature	-19～50℃
	Shell Thickness	18.47mm
	Cap Thickness	18.42mm
	Heat Treatment	Overall
	Tank Material	16MnR
	Medium Density	420kg/m3
	Other Parts	Thermometer Pressure Gauge Valve Box Vent Valve Handle Soft Tightwire Hose
Level Gauge	Nominal Pressure	2.5MPa
	Measurement Scale	50-3100mm
	Accuracy	2.5
Safety Valve	Nominal Diameter	DN80
	Breakout Pressure (BP)	1.68-1.76MPa
	Reseating Pressure	≥BPx0.8
Cargo Handling	Nominal Diameter	Liquid Inlet Pipe	DN50
		Liquid Outlet Pipe	DN80
		Gas Inlet Pipe	DN50
		Drain	DN80
		Vent	DN80
Trailer Chassis	Axle	3 axle
	Suspension	Air/mechanical suspension
	ABS	Available
