2 Axle Cargo Container Trailer 40FT Shipping Container Trailer Light Weight

Description:

Main application

Skeleton container trailer is a kind of semi-trailer frame for container transportation. Mainly used in shipyard, port, route, highway, transfer station, bridge, tunnel, multi-modal transport logistics system.

Advantages:

• Quickly stevedoring

It can be quickly loaded and unloaded, and can be directly and conveniently transferred from one conveyance to another.

• Meeting needs

It is convenient for cargo loading and unloading, and meets the individual needs of customers. The skeletal trailer made by Huilong factory has stable quality, reliable performance.

• Paint

One coat of rust proof paint, two coats of paint

• Testing

We will test the quality of the trailer before delivery

Specifications:

DIMENSIONS
Tare Weight	4800KGS	Payload	35000KGS
Overall Length	12400mm	Overall Width	2480mm
Technical Data
Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,height 500mm; Bottom Flange 16mm,width 140mm.
Axle	2 axles
	Brand name: FUWA
Suspension	Mechanical suspension with 10pcs leaf spring
Spring	Leaf spring
King Pin	FUWA brand 2” Bolt-in King Pin
Landing Gear	FUWA brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	9.0-22.5 steel wheel rim
Twist Lock	12nos. of ISO twist lock for 1x20ft container, 2x20ft container, 1x40ft container
Tyre	12R22.5 tire, 8PCS
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 4 relay valve; T30/30 Spring brake chamber; 45L air tanks
Painting	Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box, one spare tyre carrier
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
