Rod Log Cargo Container Trailer Multi - Function Corrosion Resistant Easy Operation

Description:

• Chief Application

The log transporter trailer is equipped with a lengthy cargo platform and columns on each side for fast handling operation of logs. The forest log trailer is responsible for transporting woods from the place of origin to the market.

• Easy Operation

The log transport trailer has 3 axles and the color is white. There are five fence gates on the every side of the body. Short logs or sundries can be loaded through the back gate.

Advantages:

• Multi-function

This trailer can be used not only to transport logs, but also to be used as a wall side trailer to transport agricultural products, by-products and other goods.

• Anti-shake

The trailer is equipped with an absorber which can absorb some energy of shake and ensure safe driving.

• Powerful Engine

The diesel engine can provide strong power so that the vehicle can run at a steady speed.

Specifications:

Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345; Welded by automatic Submerged-Arc processes; Top Flange 14mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm
Axle	3 axles
	Brand name: BPW, L1 or FUWA-optional upon choice
Suspension	Mechanical suspension or air suspension
Spring	Leaf spring or air bag
King Pin	JOST brand 2” Bolt-in King Pin
Landing Gear	JOST brand Two-speed; manual operating; heavy duty landing gear
Wheel Rim	8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock	12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre	11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 6 Relay Valve; T30/30+T30 Spring brake chamber; 40L air tanks
Painting	Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime; 2 coats of final paint
Accessories	One standard tool box
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
