40ft Sea Container Trailer 45t Payload High Tensile Steel Chassis Extra Durability Designed

Description:

• Main Usage

The flatbed semi-trailer is also called a container semi-trailer and designed for the transportation of various containers. Its low platform can also be used to transport construction machinery, large equipment and steel. The container semi-trailer can be used repeatedly for a long time and has sufficient strength.

• High Payload

The semi-trailer has 3 axles and the payload is 45T. This container semi-trailer has a stable structure and strong load-bearing capacity with light weight. Thus, more cargoes can be loaded.

Advantages:

• Easy Transportation

When using a container, goods can be loaded directly in the sender’s warehouse, and then transported to the consignee's warehouse for unloading. When vehicles have to be changed, goods can be still put in the container.

• Flexible Locking

12 twist locks are mounted on the semi-trailer to fix the container. So it can set 1x20ft, 2x20ft; 1x40ft container flexibly.

• Driving Safety

The flat trailer has a light body, low center of gravity and is easy to control. Therefore, it is stable during driving and is not prone to accidents.

• Digital Design

The trailer is designed with CAD softwares. The bearing surface of the frame can be built in the light of requirements from customers.

Specifications:

DIMENSIONS
Tare Weight	7700KGS	Payload	45000KGS
Overall Length	12400mm	Overall Width	2480mm
Technical Data
Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345; Welded by automatic Submerged-Arc processes; Top Flange 14mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm.
Axle	3 axles
	Brand name: BPW, L1 or FUWA
Suspension	Mechanical suspension or air suspension
Spring	Leaf spring or air bag
King Pin	JOST brand 2” Bolt-in King Pin
Landing Gear	JOST brand Two-speed; manual operating; heavy duty landing gear
Wheel Rim	8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock	12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre	11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks
Painting	Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime; 2 coats of final paint
Accessories	One standard tool box
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
