3 Axle LPG Tank Trailer

Description:

• Main Application
LPG tank trailer is the professional vehicle for storing liquefied petroleum gas. The main composition is propane which accounts for over 95%. The rest is butane. LPG has been used for the fuel of light vehicles for many years.

Advantages:

• Verified Tank
The tank is checked according to standards like "supervision regulation on safety technology for stationary pressure vessel" and "static vacuum insulated cryogenic pressure vessel". Crack detection, hydrostatic test and pneumatic test are also conducted.

• Optimized Design
During design, finite element method(FEM) and miscellaneous configurations achieve the light weight of the trailer. The optimization of the structure improves the universalization and multiple uses of components. The compact structure covers less space.

• Customized Trailer
Spatial utilization of the tank is improved by means of optimizing running gear, operative box and each accessory. The regular operation and maintenance are facilitated as well. In consideration of diversified demand of users, the tanker has the potential of modular modification based on the standard type. Modular components can be added to monitor the status of the vehicle in real time. The centralized control simplifies the operation. The comprehensive solution is offered to the scientific and effective management of vehicles.

Specifications:

Dimension
Overall Dimension	13590×2550×3995(mm)
Gross Weight	40000(kg)
Rated Load	26000(kg)
Curb Weight	14000(kg)
Tank
Tank Volume	61.9CBM
Urgency Switch Valve	Gas phase DN25 Liquid phase DN50
Ball Valve	Gas phase DN25 Liquid phase DN50
Other Parts	Thermometer Pressure gauge Drain Valve box Vent valve Handle Soft tightwire Hose
Trailer Chassis
Axle	3pcs
Wheelbase	7010+1310+1310(mm)
Suspension (Optional)	Air suspension
Tyre Spec	11.00R20-12PR,12R22.5-12PR
Tyre Qty	12
ABS	Available
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
