Aluminum Alloy Rail Curtain Side Trailer 2 Inches Kingpin Length Curtain Printable

Description:

• Main Usage

Most goods transported by the curtain side van trailer are very light, e.g.: mixed congee, cola or carton packing etc. The van trailer is suitable for the short-haul and urban logistics.

Advantages:

• Removable Structure

The van body and curtain are removable. The load and discharge operation can be completed in four directions. The forklift can be used to assist the discharge. Hence, the transportation efficiency of the logistics is greatly enhanced.

• Printable Curtain

The curtain side van trailer is usually soft caravan. The curtain is usually made by soft cord fabric and advertisements can be printed on the tarpaulin. Compared with the advertisement of container, the pattern on the tarpaulin is more appealing.

Specifications:

Dimension
Overall Dimension	14000X2500X3850
Tare Weight	8600KGS
Running Gear
Chassis	Heavy duty and extra durability designed I beam by high tensile steel Q345B; Welded by automatic submerged arc processes; Top flange 14mm, width 140mm, middle flange 6mm; bottom flange 16mm, width 140mm
Axle	3 axle, FUWA brand, 13Ton capacity
Suspension	Mechanical suspension
Spring	Leaf spring
King Pin	JOST kingpin, 2 inches
Landing Gear	JOST landing gear, manual operation, 2 speed
Wheel Rim	Steel wheel rim 9.0-22.5
Tire	Tubeless tire 12R22.5
Braking System	WABCO RE 6 relay valve; T30/30+T30 spring brake chamber; 40L air tanks
Painting	Complete chassis sand blasting to clean rust; 1 coat of anti-corrosive prime, 2 coats of final paint
Curtain Parts
Curtain Material	PVC curtains, fitted with buckles
Slide Rails	Aluminum alloy double slide rails
