Extendable Heavy Duty Trailer Automatic Steering Good Trafficability Pneumatic Brake

Description:

• Chief Application

Wind blade transport trailer is also called wind power equipment trailer and can transport wind blade. The most important feature is that the extendable function in the vertical direction. The trailer is the ideal choice for transporting overlength cargoes like wind or iron tower.

• Balance of Wind Blade

When the wind is very strong, the blade can rotate in 360 degree to avoid the wind. The center of gravity is confirmed during design and the counterweight is also used to participate in the balance. Besides, the slipway can keep the blade safe and turntable can offer the torsion.

Advantages:

• Automatic Steering

Because the overlength of the trailer increases the difficulty in steering, usually mechanical hydraulic power steering system is installed. Moreover, the rear axle can steer to the right and the left with 60 degree when the trailer suddenly swerves. Hence, the roll stability and the security of the trailer are improved.

• Good Trafficability

The good trafficability depends on the down-fixing leaf spring, low cargo bed and extendable flatbed.

• Extendable Flatbed

The length of the trailer is controlled by the extendable flatbed so that wind blade in different length can be transported.

Specifications:

Dimension	12400×2500×1540(mm)
Kingpin Setting	800(mm)
Kingpin Plate Height	1203(mm)
Wheel Base	7400mm+1310mm+1310mm
Tare Weight	7500kg
Payload	40000kg
G.V.W.R	47500kg
Landing Gear	Two speed manual operation type
Kingpin	3.5" welded type
Brake System	Dual line pneumatic brake system
ABS	YES
Brake Chamber	Type 30/30 spring brake system on all axles
Suspension	Tandem type
Axle	FUWA / BPW axle, 13 ton capacity/set, 3PCS
Tire	12.00R20, 12PCS
Rim	8.5-20, 12PCS
Floor	3mm checked plate
Twist Lock	12 sets
Main Beam	500/14/6/16
Side Beam	16# channel steel
Cross Beam	Square tube
Tool Box	1 pcs
Spare Tire Carrier	2 units
