11900x2500x3800 Tanker Truck Trailer , Diesel Fuel Tank Trailer
Anti - Wave Clapboards
Description:
• Wide Application
Fuel trailers also named as oil trailer, diesel tank, chemical fuel
tank, it can be used for the transportation and storage of
petroleum derivatives, such as gasoline, diesel, crude oil,
lubricating oil, coal tar, etc. It is widely used for road
dangerous goods long or short distance transportation.
• Durability and Safety
This tank trailer has three axes and is round in shape. The tanks
could be made in different shapes according to customer’s
requirements and the volume, there are round shape, ellipse shape,
and square round shape.
The fuel tank is made of high hardness carbon steel, so the tank is
durable and not easily deformed. This round shape fuel tank trailer
is single one compartment, but multi compartments could be made and
applied according to customer’s requirement.
In order to prevent corrosion, the tank and chassis are sand
blasted, and then have one prime paint and then two surface paint.
A tank indicator is installed in the manhole of the tank, so you
could easily check the fuel level when refueling or discharging.
Advantages:
• Inexpensive Price and Superior Quality
As a professional tanker manufacturer, our company has many years
of production experience. We use high hardness carbon steel and
advanced technology to produce reliable products. Furthermore, a
proper price is offered.
• Anti-wave Clapboards
Multiple anti-wave clapboards are installed in the tank to make the
tank more firm. The impact of liquid in the tank during driving is
reduced.
• Independent Compartments
If customers need to transport or store a variety of oil products,
some different compartments can be set.
Specifications:
| Overall Dimension (mm) | 11900x2500x3800 |
| Function | transport Fuel, Oil, Diesel |
| Thickness(mm) | Tank body: Q235/5mm carbon steel End plate: Q235/6mm carbon steel |
| Volume | 30000L-60000L |
| Axle Brand | FUWA 13Ton Axle, top brand |
| Axle Number | Three |
| Compartment | 3-9 compartments |
| Manhole Cover | 500mm manhole cover. 3 sets with 3 breath valve. |
| Ladder | Top ladder with handrail, side ladder |
| Discharge Valve | 4'' disc valve |
| Discharge Pipe | 4'' seamless steel tube |
| Suspension System | Leaf spring suspension |
| Bottom Valve Quantity | 3 units |
| Steel Spring | 10/10/10 leaf spring suspension 90mm width, 13mm thickness |
| The Material of Main Beam | beam height | 500 mm |
| upper plate | 14 mm |
| down plate | 16 mm |
| middle plate | 8 mm |
| Tire Type and Quantity | 12R22.5 |
| Traction Pin | 50mm/90mm, JOST brand |
| Spare Wheel Bracket | 2 pieces |
| Tool Box | 1 Standard |
| Landing Gear | Standard brand 28ton external, 2 speed |
| Brake System | Dual Line braking system |
| Brake Air Chamber | Six big double air chambers |
| Electrical System | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
| Tail lamp with turn signal, brake light & reflector, side lamp etc. |
| One set 6-core standard Cable. |
| Side Guard | According to customer’s requirement |
