Thermal Insulation Chemical Tank Trailer Fiber Glass Simple Structure Easy Maintenance

Description:

This bitumen transportation tank truck is a double layer carbon steel tank with a diesel burner. The inner tank is a carbon steel tank with several baffles. The diesel burner and the heating tubes inside the tank consist of the heating system to provide continuous heating to the bitumen. Only the bitumen is heated into a fluid flow, it could discharge easily.

The running gear is 3 axle mechanical suspension type with tubeless tyre. The payload of the chassis is 45Tons. It is durable and long lasting trailer chassis.

Application:

The thermal insulation tank trailer is to load and distribute the bitumen, asphalt, or other types of thick liquid, which needs to be heated for discharging. It is widely used for road construction and other types of construction works.

Advantages:

1. Big volume and big discharge flow for efficient works.
2. Good quality burner to provide effective and sufficient heating to the vehicle.
3. Simple structure, easy function and maintenance.

Specifications:

Dimension
Overall Dimension	12600x2500x3350mm
Tare Weight	10600KGS
Tank
Shape	Monoblock shape tank
Total Volume	30000L
Tank Body Material	Carbon steel 5mm
Tank End Plate	Carbon steel 6mm
Compartment	Single compartment
Insulation Material and Thickness	Fiber glass, 50mm
Outside Sheet	1.2mm steel sheet
Heating System	Diesel Heating, Electric Heating, Coal Heating optional upon requirement
Pump In and Out System	Gear type screw type optional upon requirement
Trailer Chassis
Main Beam	Special design I beam
Axle	BPW axle
Landing Gear	JOST landing gear
Kingpin	JOST kingpin 2 inches
Suspension	Mechanical suspension
Braking System	T30/30 air chamber, WABCO relay valve
Tire	12R22.5
Wheel Rim	9.0-22.5
Accessories	Tool box, spare tire carrier
